Speak with a real person who will go out of the way to help!
The picture shown is for representative purposes only. The actual product delivered corresponds to the part number you ordered.
Revisions: Ser A
Description: The 20AB4P2A3AYNNNC0 manufactured by Allen Bradley is a 1 HP rated drive. It is a 4.2 A rated unit. This PowerFlex 70 has a kW rating of 0.75 kW. In addition, this PowerFlex 70 AC drive is a 240V AC VFD and has a full numeric LCD human interface module on this drive. It is a size A frame.
Texnite is not an authorized distributor, reseller, or representative of the products displayed or mentioned on this website. All product names, trademarks, brands, and logos used or referred to on this site remain the property of their respective owners. The depiction, description, or sale of products showcasing these names, trademarks, brands, and logos is solely for identification purposes and does not imply or intend to indicate any affiliation with or authorization by any rights holder.
Texnite is NOT an authorized distributor, affiliate or representative for the Manufacturer.
Product is surplus. Manufacturer's warranties do NOT apply.
Product is surplus. Manufacturer's warranties do NOT apply.
Allen Bradley 20AB4P2A3AYNNNC0 PowerFlex 70 AC Drive 4.2 A at 1 Hp 20A
Allen Bradley- Part
- #20AB4P2A3AYNNNC0
- Condition:
- New
Revisions: Ser A
Description: The 20AB4P2A3AYNNNC0 manufactured by Allen Bradley is a 1 HP rated drive. It is a 4.2 A rated unit. This PowerFlex 70 has a kW rating of 0.75 kW. In addition, this PowerFlex 70 AC drive is a 240V AC VFD and has a full numeric LCD human interface module on this drive. It is a size A frame.
QUICK DELIVERY
FREE SHIPPING
2 YEAR WARRANTY
EASY RETURNS
Reviews
20AB4P2A3AYNNNC0
Description: PowerFlex 70
Input Voltage
240 (208) VAC, 3 PH
240 (208) VAC, 3 PH
Output Current
4.2 Amps
4.2 Amps
Enclosure
Panel Mount - IP20 / NEMA Type 1, with conformal coating
Panel Mount - IP20 / NEMA Type 1, with conformal coating
Frame Size
Frame Size A
Frame Size A
Output Current Information
Output Amps: 4.2A Cont, 4.8A 1 Min, 6.4A 3 Sec
Output Amps: 4.2A Cont, 4.8A 1 Min, 6.4A 3 Sec
Control and I/O
Enhanced Control
Enhanced Control
Brake IGBT
Brake IGBT
Brake IGBT
Brake Resistor
No Brake Resistor
No Brake Resistor
EMC Filtering Options
Without CE compliant filter
Without CE compliant filter
Base Plus Options
Factory Assembled
Factory Assembled
Human Interface Module
LCD Display, Full Numeric Keypad
LCD Display, Full Numeric Keypad
Internal Communication Module
No Communication Module
No Communication Module
Feedback Option
No Feedback
No Feedback
The product offered is sold as used surplus. Texnite is not an authorized surplus dealer or affiliate of the Manufacturer associated with this product. It's possible that the product may contain older date codes or belong to an earlier series compared to items available directly from the factory or authorized dealers. As Texnite is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply.
Although numerous Allen-Bradley PLC products may contain pre-installed firmware, Texnite does not confirm whether a PLC product has firmware or if the firmware corresponds to the revision level required for your specific application. Additionally, Texnite does not guarantee or imply your capability or entitlement to download or acquire firmware for the product from Rockwell, its distributors, or any other source. Furthermore, Texnite does not assert your right to install any such firmware on the product. Texnite neither obtains nor provides firmware on behalf of customers. It remains your responsibility to adhere to the terms stated in any End-User License Agreement or a similar document related to obtaining or installing firmware.
Technical Specifications for 20AB4P2A3AYNNNC0
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 20AB4P2A3AYNNNC0 |
| Voltage | 240V AC |
| Ph | 3 |
| Amps | 4.2 |
| kW(Hp) | 0.75 (1.0) |
| Frame | A |
| Enclosure | Panel Mount - IP 20, NEMA/UL Type 1 |
| Interface Module | Full Numeric LCD |
| Type | Manual |
| w/Brake | Yes |
| w/Resistor | No |
| Rating | Not Filtered A & B Frames (Optional) C, D & E Frames |
| Network Type | None |
| Control | Enhanced |
| Safe Off | No |
| Feedback | No Feedback - Enhanced Control |
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 20AB4P2A3AYNNNC0 |
| Voltage | 240V AC |
| Ph | 3 |
| Amps | 4.2 |
| kW(Hp) | 0.75 (1.0) |
| Frame | A |
| Enclosure | Panel Mount - IP 20, NEMA/UL Type 1 |
| Interface Module | Full Numeric LCD |
| Type | Manual |
| w/Brake | Yes |
| w/Resistor | No |
| Rating | Not Filtered A & B Frames (Optional) C, D & E Frames |
| Network Type | None |
| Control | Enhanced |
| Safe Off | No |
| Feedback | No Feedback - Enhanced Control |
About 20AB4P2A3AYNNNC0
The 20AB4P2A3AYNNNC0 is an Allen-Bradley adjustable frequency drive. The drive is classified as a PowerFlex 70 series drive. It is designed to offer a compact package of power and control with an easy to use operator interface that has been designed to meet the users’ needs. The 20AB4P2A3AYNNNC0 features a Horsepower rating of 1.0 Horsepower and it is a 3-phase drive. The drive comes with an amperage rating of 4.2 Amps featuring the A frame size. It comes with the panel-mounted IP20 NEMA/UL type 1 enclosure and an LCD screen HMI. The 20AB4P2A3AYNNNC0 features an enhanced control and performance with no feedback option. It comes with an optional internal communication module for ensuring a fast and efficient control. The internal communication module also ensures data exchange with the host controllers over popular interfaces. The popular interfaces for Allen-Bradley Powerflex drives include the Workbench, DeviceNet, Ethernet, ControlNet, and also serial communications interface.
The 20AB4P2A3AYNNNC0 comes with no brake resistor on the panel. Thus, it requires no extra panel space while it supplies a large amount of braking torque for a short period. The 20AB4P2A3AYNNNC0 features the Volts per Hertz control and also the vector control with the FORCE technology. This ensures the drive supports an outstanding torque and speed regulation with or without the encoder feedback. The 20AB4P2A3AYNNNC0 also features the sensorless vector control.
Technical Description of 20AB4P2A3AYNNNC0
This Allen Bradley PowerFlex 70 is a 0.75 (1.0) kW(Hp) AC Drive. This PF 70 comes with Enhanced Control, a Full Numeric LCD, and w/Brake. This AB VFD is Frame size A and powered with 240V AC 3 Phase and 3 Amps.
