Allen Bradley 1305-BA02A-ES

The Allen-Bradley 1305-BA02A-ES drive is an adjustable frequency AC drive that uses 380 to 460 Volts AC input voltage with a frequency of 50 to 60 Hertz. This drive is part of the 1305 AC Drives product line. It features the IP 30, NEMA Type 1 enclosure and it has no human-machine interface module. This is a 3-phase voltage input drive with an output current of 1.6 Amps as well as a motor rating of 0.55 kilowatts or 0.75 Horsepower. It comes with Spanish as the default language. The 1305-BA02A-ES AC drive is designed with control logic and it can prevent overcurrent and overvoltage trips and it also limits the output current to a 200% rating in case an intermittent overload occurs. Its carrier frequency can be adjusted by 100-Hertz increments, thus producing quiet operation and reduced mechanical resonance. Additionally, this drive features an integral protective feature that helps to power-up ground faults, and to prevent overload, over-heating as well as short-circuiting on the output phases.

The Allen-Bradley 1305-BA02A-ES variable speed drive has a unique torque performance, which can be maintained through the entire speed range. When a high torque is required, this drives provides a dynamic response that helps in maintaining the speed and current control. It uses a powerful and intelligent technology referred to as IGBT that helps to provide faster output transistor switching. The 1305-BA02A-ES AC drive is configurable for the 2-wire as well as 3-wire control. The drive features 2 programmable outputs, which are 1 relay output and 1 transistor output. With an inherent braking capability, it preserves a sufficient amount of panel space, lowers the cost of installation, and reduces the external braking requirements. The front cover of this AC drive makes it easy for the operators to access, maintain, and control the power of the drive.
