The picture shown is for representative purposes only. The actual product delivered corresponds to the part number you ordered.
Description: The Allen-Bradley 2090-UXNPBMP-10S09 power cable is a standard, non-flex cable that is designed for the MP Series and 1326AB Series servo motors. It comes with an 8 AWG wire size, 460 Volts AC voltage, and 9 meters of cable length.
Texnite is not an authorized distributor, reseller, or representative of the products displayed or mentioned on this website. All product names, trademarks, brands, and logos used or referred to on this site remain the property of their respective owners. The depiction, description, or sale of products showcasing these names, trademarks, brands, and logos is solely for identification purposes and does not imply or intend to indicate any affiliation with or authorization by any rights holder.
Texnite is NOT an authorized distributor, affiliate or representative for the Manufacturer.
Product is surplus. Manufacturer's warranties do NOT apply.
Product is surplus. Manufacturer's warranties do NOT apply.
Allen Bradley 2090-UXNPBMP-10S09 MP-Series 9 m Length Power Cable
Allen Bradley- Part
- #2090-UXNPBMP-10S09
- Condition:
- New
Description: The Allen-Bradley 2090-UXNPBMP-10S09 power cable is a standard, non-flex cable that is designed for the MP Series and 1326AB Series servo motors. It comes with an 8 AWG wire size, 460 Volts AC voltage, and 9 meters of cable length.
QUICK DELIVERY
FREE SHIPPING
2 YEAR WARRANTY
EASY RETURNS
Reviews
2090-UXNPBMP-10S09
Description: Accessories for Motion Products
2090 Cable, UX and XX
Cable, 460V,Non-Flex,Motor Power,MP,10 Gauge,9M.
Cable, 460V,Non-Flex,Motor Power,MP,10 Gauge,9M.
The product offered is sold as used surplus. Texnite is not an authorized surplus dealer or affiliate of the Manufacturer associated with this product. It's possible that the product may contain older date codes or belong to an earlier series compared to items available directly from the factory or authorized dealers. As Texnite is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply.
Although numerous Allen-Bradley PLC products may contain pre-installed firmware, Texnite does not confirm whether a PLC product has firmware or if the firmware corresponds to the revision level required for your specific application. Additionally, Texnite does not guarantee or imply your capability or entitlement to download or acquire firmware for the product from Rockwell, its distributors, or any other source. Furthermore, Texnite does not assert your right to install any such firmware on the product. Texnite neither obtains nor provides firmware on behalf of customers. It remains your responsibility to adhere to the terms stated in any End-User License Agreement or a similar document related to obtaining or installing firmware.
Technical Specifications for 2090-UXNPBMP-10S09
| Brand | Allen-Bradley / Rockwell Automation |
| Series | 2090 Cables |
| Part Number | 2090-UXNPBMP-10S09 |
| Product Description | Power Cable |
| Connector Type | Motor End Bayonet Connector, Drive End Flying Leads |
| Motor Connector | Straight |
| Flex Option | Standard, Non-flex |
| Voltage Rating | 460 Volts |
| Cable length | 9 meters |
| Wire Size | 8 AWG |
| Series | Miscellaneous Allen Bradley |
| Cable Jacket Color | Black |
| Compatibility | MP-Series, 1326AB-Series |
| Applicable Drives | 2098-IPD-075, 100, 150, 220, HV100, HV150, HV220 |
| Brand | Allen-Bradley / Rockwell Automation |
| Series | 2090 Cables |
| Part Number | 2090-UXNPBMP-10S09 |
| Product Description | Power Cable |
| Connector Type | Motor End Bayonet Connector, Drive End Flying Leads |
| Motor Connector | Straight |
| Flex Option | Standard, Non-flex |
| Voltage Rating | 460 Volts |
| Cable length | 9 meters |
| Wire Size | 8 AWG |
| Series | Miscellaneous Allen Bradley |
| Cable Jacket Color | Black |
| Compatibility | MP-Series, 1326AB-Series |
| Applicable Drives | 2098-IPD-075, 100, 150, 220, HV100, HV150, HV220 |
About 2090-UXNPBMP-10S09
The Allen-Bradley 2090-UXNPBMP-10S09 power cable belongs to the Allen-Bradley 2090 series of power and feedback cables. The features of the cable ensure easy connection to motors and drives and reduce the risk of failure due to cable flexing. It maximizes the power density of the system by its low capacitance design. This cable comes with a bayonet connector at the motor end and flying leads at the drive end. For drive end terminations, a breakout component kit is needed. It is 9 meters in length and 8 AWG in wire size. The Allen-Bradley 2090-UXNPBMP-10S09 power cable has a convenient assembly process and effective performance even when the system is exposed to vibrations.
The 2090-UXNPBMP-10S09 power cable consists of special conductor insulation made to withstand in harsh environments. The cable contains a bundle of copper wires which are known as conductors to transmit the power. It is short and it transmits power at a more stable voltage than long cables. This cable is designed to be used with MP Series motors and 1326 Series motors. Some of the applicable drives for this cable are the 2098-IPD-075, 100, 150, 220, HV100, HV150, and HV220 drives. Make sure to insulate both ends of the unused conductors in the power cable. The brown, black, blue, and green/yellow color wires must be connected to the U, V, W, and GND ports of the drive and motor, respectively. Its locking mechanism ensures a permanently sealed condition even with moderate levels of shock or vibration. Cable lengths should ideally be trimmed to fit the application. The 2090-UXNPBMP-10S09 power cable is designed for fixed and dynamic applications such as automotive and electronic assembly applications.
