Allen Bradley 1336-F1-SP17A

The 1336-F1-SP17A is a spare fuse for the 1336 series of adjustable frequency drives which are manufactured by Allen Bradley. It is compatible with the PLUS FORCE, and IMPACT drives. The fuse is supplied with the 30HP and 40HP models which are having a C-Frame type. The 1336-F1-SP17A is known as a bus fuse and has a rating of 125 Amperes and 700 Volts. The size of the fuse is 5.09 x 1.50 inches. When replacing the fuse, ensure that the power to the drive is turned completely off, in order to prevent any injury due to electric shock while replacing the fuse. Also make sure the bus capacitors have been fully discharged as they may hold charge even after the power is turned OFF. Make sure to follow the safety instructions as stated by the manufacturer, in order to prevent any injury and hazard. The device should be opened by a person trained and familiar with the system. The user should also wear electrostatic straps in order to prevent electrostatic discharge from damaging the equipment; after replacing the fuse, ensure that the enclosure is installed correctly, and before turning ON the power supply to the equipment, make sure all the connections are secured and done as per the manufacturer's specifications.
