Allen Bradley 20AD5P0A3AYNARC0 Used Surplus

The 20AD5P0A3AYNARC0 is a variable frequency drive from the PowerFlex 70 series of drives manufactured by the Allen-Bradley branch of Rockwell Automation. This is a type of electronic control device that is designed to change the voltage and the frequency supplied to the AC motor. This type of action will result in the change of the motor speed, so the 20AD5P0A3AYNARC0 can simply calculate how to turn the motor speed up or down to meet the speed set point. while doing the speed reduction, this device ultimately reduces power consumption and saves energy. This is a 3-phase module that requires a 480 Volts AC power supply and it has a 3 Horsepower (2.2 kW) rating. The amperage of the device is 5 Amps, and it comes with an interface option that includes an LCD and a numeric keyboard.

The 20AD5P0A3AYNARC0 drive features 6 digital inputs which can be programmed to adapt the drive to application needs. The drive works with control algorithms called Volt per Hertz control, Sensorless Vector control, and FORCE control. The Allen-Bradley 20AD5P0A3AYNARC0 is designed to save space while providing a high level of control of the motor torque and speed. It is particularly convenient for motor speed control at the machine level, but it can be implemented in sophisticated and technically demanding systems too. This drive is housed in an open type IP20/NEMA enclosure which has a low mechanical protection rating, but it is a good solution for faster device cooling and it reduces the overall size of the enclosure. The item is approximately 235 millimeters (9.24 inches) high, 172 millimeters (6.76 inches) wide, and 180 millimeters (7.08 inches) deep.
