3 in stock
Speak with a real person who will go out of the way to help!
The picture shown is for representative purposes only. The actual product delivered corresponds to the part number you ordered.
- 20AB015A3AYNANC0
- AC DRIVE
- ADJUSTABLE FREQUENCY
- POWERFLEX 70
- 240 VAC
- 3 PHASE
- 15.3 AMP
- 4 KW
- 5 HP
- PANEL MOUNT
- INTERFACE MODULE - FULL NUMERIC LCD
- WITH BRAKE
- FILTERED EMISSION CLASS
- ENHANCED CONTROL
- NO FEEDBACK
- FACTORY WARRANTY DOES NOT APPLY. TEXNITE 1-YEAR WARRANTY INCLUDED
Texnite is not an authorized distributor, reseller, or representative of the products displayed or mentioned on this website. All product names, trademarks, brands, and logos used or referred to on this site remain the property of their respective owners. The depiction, description, or sale of products showcasing these names, trademarks, brands, and logos is solely for identification purposes and does not imply or intend to indicate any affiliation with or authorization by any rights holder.
Texnite is NOT an authorized distributor, affiliate or representative for the Manufacturer.
Product is surplus. Manufacturer's warranties do NOT apply.
Product is surplus. Manufacturer's warranties do NOT apply.
Allen Bradley 20AB015A3AYNANC0 Used Surplus
Allen Bradley- 20AB015A3AYNANC0
- AC DRIVE
- ADJUSTABLE FREQUENCY
- POWERFLEX 70
- 240 VAC
- 3 PHASE
- 15.3 AMP
- 4 KW
- 5 HP
- PANEL MOUNT
- INTERFACE MODULE - FULL NUMERIC LCD
- WITH BRAKE
- FILTERED EMISSION CLASS
- ENHANCED CONTROL
- NO FEEDBACK
- FACTORY WARRANTY DOES NOT APPLY. TEXNITE 1-YEAR WARRANTY INCLUDED
QUICK DELIVERY
FREE SHIPPING
1 YEAR WARRANTY
EASY RETURNS
Reviews
Technical Specifications for 20AB015A3AYNANC0
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 20AB015A3AYNANC0 |
| Voltage | 240V AC |
| Ph | 3 |
| Amps | 15.3 |
| kW(Hp) | 4.0 (5.0) |
| Frame | C |
| Enclosure | Panel Mount - IP 20, NEMA/UL Type 1 |
| Interface Module | Full Numeric LCD |
| Type | Manual |
| w/Brake | Yes |
| w/Resistor | No |
| Rating | Filtered A & B Frames (Optional) C, D, & D Frames (Standard) |
| Network Type | None |
| Control | Enhanced |
| Safe Off | No |
| Feedback | No Feedback - Enhanced Control |
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 20AB015A3AYNANC0 |
| Voltage | 240V AC |
| Ph | 3 |
| Amps | 15.3 |
| kW(Hp) | 4.0 (5.0) |
| Frame | C |
| Enclosure | Panel Mount - IP 20, NEMA/UL Type 1 |
| Interface Module | Full Numeric LCD |
| Type | Manual |
| w/Brake | Yes |
| w/Resistor | No |
| Rating | Filtered A & B Frames (Optional) C, D, & D Frames (Standard) |
| Network Type | None |
| Control | Enhanced |
| Safe Off | No |
| Feedback | No Feedback - Enhanced Control |
About 20AB015A3AYNANC0
The 20AB015A3AYNANC0 is an Allen-Bradley PowerFlex 70 series drive. The drive features a power voltage rating of 240 Volts AC. The 3-phase drive features an output current rating of 15.3 Amps and a Horsepower rating of 5.0 Horsepower. The 20AB015A3AYNANC0 features the panel-mounted IP20/NEMA Type 1 enclosure with a conformal coating. It also features the C frame size with enhanced control. The 20AB015A3AYNANC0 features brake type IGBT with no brake resistor. It also features the second environment filter per the CE EMC directive. It comes with the ambient operating temperature range of 0 to 50 degrees Celsius, while the 20AB015A3AYNANC0 features integral electromagnetic compatibility filtering for providing the drive with a compact all-in-one package solution for meeting the EMC requirements, including the CE regulations.
The 20AB015A3AYNANC0 LCD HMI ensures that the drive offers an easy configuration and commissioning process. This is through the large and easy-to-read 7-line 21-character backlit display. It also features support for a variety of languages and it comes with alternative function keys that act as shortcuts to various common tasks. The 20AB015A3AYNANC0 features the Volts per Hertz and sensorless vector control. It also comes with the vector control with FORCE technology or without an encoder. The module also features the slip compensation for delivering a minimum of 0.5% open-loop speed regulation across a wide speed range. The drive also features safe torque-off which is the first offering available with the DriveGuard series of safety solutions. It comes with the sleep or wake control for the analog control of the start and stop modes.
Technical Description of 20AB015A3AYNANC0
This Allen Bradley PowerFlex 70 is a 4.0 (5.0) kW(Hp) AC Drive. This PF 70 comes with Enhanced Control, a Full Numeric LCD, and w/Brake. This AB VFD is Frame size C and powered with 240V AC 3 Phase and 3 Amps.
