Allen Bradley 1336-CONV-SP16A Used Surplus

The Allen-Bradley 1336-CONV-SP16A is a D-framed bus fuse and busbar upgrade kit that comes with a higher amperage bus fuse and fuse adapter. Note that users can use this bus kit for the 1336 adjustable frequency drives with a 230V voltage rating, specifically the FORCE, IMPACT, PLUS, and the PLUS II drives (with CLASSIC drives being the only incompatible type of 1336 drives), and only 1 bus kit can be installed per drive. The 1336-CONV-SP16A bus kit has a voltage of 230V, a current of 300 A, and an HP rating of 50 HP.



All of the 1336 series drives feature UL panel recognition and various ports for I/O and communication. Some of these ports are RS232/422/485 ports, analog I/O, single-point RIO, Enhanced DeviceNet ports, and DeviceNet ports. These drives also have a standard hardware input enable located at the drive’s non-programmable input, specifically at the Terminal 30. This input will automatically be checked by the drive prior to a start and when interrupted by opening the input, the operation of the drive will be interrupted and it will do a ‘coast to stop’, ignoring the pre-programmed stop mode. users can safely install the 1336-CONV-SP16A bus kit on a compatible D frame 1336 drive, regardless of which application or operation, it is to be used with. To be precise, PLUS II, CLASSIC, and PLUS drives are suited for general performance ones, while IMPACT and FORCE drives are ideal for high-performance applications, and the 1336-CONV-SP16A will help with all of these applications. These drives are also equipped with various safety features, such as an output ground fault, motor overload, output short circuit, and under and overvoltage.
